PCI-GPIB+ Specifications
Previous
Step
104
Declaration of Conformity
according to ISO/IEC Guide 22 and BS 7514
Manufacturer's Name: National Instruments
Manufacturer's Address: 6504 Bridge Point Parkway
Austin, Texas 78730-5039
USA
The manufacturer hereby declares that the product
Product Name: GPIB Interface Card for PCI with Analyzer
Model Numbers: PCI-GPIB+
Product Options: All
conforms to the following standards or other normative documents:
Electromagnetic Emissions: EN 55022: 1987
(by Council Directive 89/336/EEC) CISPR 22: 1985 Class B
Electromagnetic Immunity: EN 50082-1: 1992
(by Council Directive 89/336/EEC) IEC 801-2: 1991 4.0 kV by Contact
8.0 kV by Air
IEC 801-3: 1991 3.0 V/m
26 .. 1000 MHz
IEC 801-4: 1988 0.5 kV Signal Lines
1.0 kV AC Power Lines
Safety: EN 61010-1: 1993
(by Council Directive 73/23/EEC)
Supplementary Information
X2 grade shielded cable is required for electromagnetic compatibility and is available from the manufacturer.
When and Where Issued
1 May 1997
Austin, Texas USA
Eric Lifsey
Compliance Engineer
Marks of Compliance European Contact
National Instruments Corporation (U.K. Ltd.)
21 Kingfisher Court, Hambridge Road
Newbury, Berkshire RG14 5SJ
Tel (44) 1635 523545
Fax (44) 1635 523154

NI GPIB Series Specifications

General

Operating Systems Supported	Windows, Linux, macOS
Driver Software	NI-488.2
Bus Interface	IEEE 488
Data Transfer Rate	Up to 8 MB/s
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Maximum Cable Length	20 m total system length
Number of Devices Supported	Up to 14 devices per bus
