GPIB-1394 Specifications

Step

GPIB-1394 Specifications

Table 19. GPIB-1394 Hardware Characteristics

Characteristic Specification

Dimensions 14.6 cm by 21.3 cm by 3.8

(5.8 in. by 8.4 in. by 1.5 in.)

Power Requirement +9 to 30 VDC 5 W Typical

at 9 VDC 580 mA Typical

1 A Maximum

I/O Connector IEEE 488 Standard 24-Pin

Three IEEE 1394 6-pin sockets

1394 Ports S400, S200, S100 data rates

GPIB Port Compatible with IEEE 488.1 and

IEEE 488.2

Operating Environment

Component Temperature

Relative Humidity

0° to 55° C

0% to 90%, Noncondensing

Storage Environment

Temperature

Relative Humidity

–20° to 70° C

10% to 90%, Noncondensing

EMI FCC Class A Certified

Questions and Answers:

Need help?

Do you have a question about the NI GPIB Series and is the answer not in the manual?

NI GPIB Series Specifications

General

Operating Systems Supported	Windows, Linux, macOS
Driver Software	NI-488.2
Bus Interface	IEEE 488
Data Transfer Rate	Up to 8 MB/s
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Maximum Cable Length	20 m total system length
Number of Devices Supported	Up to 14 devices per bus
