GPIB-PCII/IIA Specifications
Table 21. GPIB-PCII/IIA Hardware Characteristics
Characteristic Specification
Dimensions 10.7 cm by 11.1 cm
(4.2 in. by 4.35 in.)
Power Requirement
(from PC/XT/AT I/O channel)
+5 VDC 50 mA typical
120 mA maximum
I/O Connector IEEE 488 Standard 24-pin
Operating Environment
Component Temperature
Relative Humidity
0° to 55° C
10% to 90%, noncondensing
Storage Environment
Temperature
Relative Humidity
–20° to 70° C
5% to 90%, noncondensing
EMI FCC Class B Certified
Table 22. GPIB Software Transfer Rate for the GPIB-PCII/IIA
Transfer Method Maximum GPIB Transfer Rate
3-wire (IEEE 488) 300 kbytes/s*
* Actual speed may vary considerably from speed shown because of system and
instrumentation capabilities.
