PC/104-GPIB Specifications

Step

111

PC/104-GPIB Specifications

Table 37. PC/104-GPIB Hardware Characteristics

Characteristic Specification

Dimensions 9.7 cm by 9.1 cm

(3.8 in. by 3.6 in.)

Power Requirement

(from PC AT I/O Channel)

+5 VDC 50 mA Typical

100 mA Maximum

I/O Connector 20 in. Ribbon Cable

Terminated with Panel-Mount

IEEE 488 Standard 24-Pin

Operating Environment

Ambient Temperature

Relative Humidity

0° to 55° C

10% to 90%, Noncondensing

Storage Environment

Temperature

Relative Humidity

–40° to 85° C

5% to 90%, Noncondensing

EMI FCC Class A Verified
