PMC-GPIB Specifications

Step

114

PMC-GPIB Specifications

Table 39. PMC-GPIB Hardware Characteristics

Characteristic Specification

Dimensions 7.4 cm by 14.9 cm

(2.9 in. by 5.9 in.)

Power Requirement

(from PMC bus)

+5 VDC 600 mA Typical

800 mA Maximum

I/O Connector Micro D-sub 25-pin

PCI Signaling Environment +5 VDC

Power Dissipation 3 Watts Typical

4 Watts Maximum

Operating Environment

Temperature

Relative Humidity

0° to 55° C

10% to 90%, Noncondensing

Storage Environment

Temperature

Relative Humidity

–20° to 70° C

5% to 90%, Noncondensing

EMI FCC Class A Verified

Questions and Answers:

Need help?

Do you have a question about the NI GPIB Series and is the answer not in the manual?

NI GPIB Series Specifications

General

Operating Systems Supported	Windows, Linux, macOS
Driver Software	NI-488.2
Bus Interface	IEEE 488
Data Transfer Rate	Up to 8 MB/s
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Maximum Cable Length	20 m total system length
Number of Devices Supported	Up to 14 devices per bus
