National Instruments Corporation
Configure and Install Your AT-GPIB/TNT
Go
Back
3
Figure 1. AT-GPIB/TNT Parts Locator Diagram
1 Product Name,
Revision Letter, and
Assembly Letter
2 Base I/O Address
3 Serial Number
4 DMA Channel
5 Interrupt Line (IRQ)
6 Shield Ground
1
4 65
2 3
