Configure and Install Your PC/104-GPIB
Go
Back
44
Figure 8. PC/104-GPIB Parts Locator Diagram
1 Product Name and Assembly Number
2 Serial Number
3 Base I/O Address
4 DMA Channel
5 Interrupt Line (IRQ)
6 Shield Ground
®
12
3
4
5
6
