PXI-GPIB Installation
Next
Step
Previous
Step
76
Figure 19. Installing the PXI-GPIB
1 Injector/Ejector Handle (In Down Position)
2 PXI-GPIB Board
3 PXI Chassis
4 Injector/Ejector Rail
8
7
6
5
4
3
2
1
