General Information 14Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
Ref
VISUAL INSPECTION ITEMS
Comments
OK or
N/A
Defect Codes
(circle)
Does Not
Work
17 Scrub Brushes (check for wear and rotate) A B D W
18 Scrub Brush Motor Carbon Brushes Wear Limit 3/8” B L W
19 Scrub Brush Gimbals In Brush Plates W
20 Auto Tension Belt – Wear and Tension (cylindrical) A D W
21 Spring Retainers In Brush Plates D
22 Scrub Deck Skirt Position Slight Flare A B W
23 Solution Solenoid Valve C L
24 Solution Tank, Delivery Hoses & Filter Clean Filter Screen C L
25 Vacuum Motor Carbon Brushes Wear Limit 3/8” W
26 Vacuum Motor Gaskets & Filters L W
27 Vacuum Float Ball & Cage Assembly Clean Float C M
28 Recovery Lid Gasket C D L
29 Recovery Tank Drain Hose & Cap Flush C L
30 Recovery Tank Strainer Basket Clean C D
31 Squeegee Pick-Up Tool and Hose Back Flush C L
32 Squeegee Blades (clean & rotate) A C D W
33 Squeegee Lift Actuator Motor & Cable A B D
34 Battery Condition (clean & water) Load Test C W
35 Drive Wheel Motor Carbon Brushes Wear Limit 1/4” C W
36 Drive Pedal Neutral Return A C
37 Steering Chain Lube & Tension 1/4” Deection A B C
38 Steering Column Universal Joint A D
39 Rear Wheels C
40 Hopper (Cylindrical only C
WORK COMPLETED BY: ACKNOWLEDGED BY:
__________________________________ _________ ________________________________ ________
Service Technician Signature Date Customer Signature Date
