Scrub System: Disc, Cylindrical, & Boost 63Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
Brush Motor Contactor
Warning: Disconnect the battery connector before servicing machine. This procedure involves
high amperage components. An inadvertent short circuit can damage the components or
your tools and equipment.
1. Turn off the key and disconnect the main battery
connector.
2. Remove the Electrical Panel Cover described on
page 37.
3. Remove the incoming and outgoing power cables
from the terminal posts (11A & 11B).
4. Remove the control wires from the terminal posts
(11C & 11D).
5. Remove the two nuts (11E) that secure the
contactor to the electrical panel, and remove the
contactor.
11
11B
11A
11C
11D
11E
11E
