Control System 19Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
Main Machine Controller Programming
The Main Machine Controller is programmable for machine specic functions and parameters through a
hidden menu system. This is a required task when replacing the controller with a new controller or changing
features. The listings below and following sections describe the parameters to be programmed. Refer to
Navigating the Hidden Menus on page 20.
Programming Menu Outline
1. Deck Type
• 28 Inch Boost
• 40 Inch Disc
• 34 Inch Disc / BR855
• 28 Inch Cyl / BR755C
• 28 Inch Disc / BR755
2. Battery Charger
• AGM Fullriver 25A †
• Wet 15A
• Gel-AGM 25A
• Gel Exide 25A
• AGM Discover 25A
• Wet 25A
• None
3. Chemical Selection
• Onboard Chemical
• No Onboard Chemical
4. Detergent Mode
• 1. Off
5. Vacuum Selection
• 2 Vacuum Motors
• 1 Vacuum Motor
6. Low Voltage Cutout
• Main Free Battery 70%
LVC = 21.75V
• Wet Battery 80%
LVC = 20.55V
7. Max Scrub Speed
• 100% of Transport
8. Lockout Brush Pre (Pressure)
• 1. None
9. Lockout Sol Flows (Solution)
• 1. None
10. Recovery Tank Full
• 1. Disabled
11. Chemical Rate Bias
• 1. None
12. Deck Down Time
• x.x Seconds
(1.0 to 5.0 in 0.1 increment)
13. Restore Defaults
• 2. Yes
• 1. No
14. Display Rev Level
• Rev xx
15. Fault Recall
• -- (none)
16. Fault Detection
• 1. Enabled
• 2. Disabled
17. Service Test Mode
• See Service Test Mode on
page 22
18. Backup Alarm Vol (Volume)
• 4. High
• 3. Medium
• 2. Low
• 1. Off
19. FWD Alarm Vol (Forward)
• 4. High
• 3. Medium
• 2. Low
• 1. Off
20. Horn Volume
• 4. High
• 3. Medium
• 2. Low
• 1. Off
21. Panel Test
† For North and South American (Clark) models equipped with Fullriver brand batteries only. Selecting this
option on a Nilsk-Alto model charger will result in that charger to operate with a “Gel-AGM-15A” mode.
