Recovery System 54Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
Specifications
Parameter Range
Vacuum Lift, Single Motor • Sealed water lift = 61 in-H
2
O (15 kPa)
• 1-inch open hole aperture = 8 in-H
2
O (2 kPa)
Vacuum Lift, Dual Motor • Sealed water lift = 59 in-H
2
O (15 kPa)
• 1-inch open hole aperture = 21 in-H
2
O (5 kPa)
Contactor Coil Resistance • 58.3 Ω
Motor Amperage • Single Motor, with squeegee off oor = 19.8 A
• Dual Motor, with lid open = 40 A
• Dual Motor, with 1” hole = 38 A
• Dual Motor, blocked inlet = 30 A
Special Tools
Vacuum Pressure Gauge 1-inch open hole adapter
part number 56205281 Fabricated from PVC
