Control System 18Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
Component Locations
Vacuum
Contactor
Brush
Contactor
Wheel Drive
Controller
150 Amp
Fuse
Battery Pos.
Terminal
Battery Neg.
Terminal
70 Amp
Breaker
10 Amp
Breaker
E-Stop
Seat
Switch
Main Machine
Controller
Drive Pedal
Sensor
Key Switch
