Scrub System: Disc, Cylindrical, & Boost 60Service Manual – Focus II / Scrubtec R6 Rider Autoscrubber
6. From the right side of the machine,
remove the retaining key (1C) and link
pin (1B) that secures the scrub deck to
the lift arms. Take care not to loose the
spacers (1D).
7. Slide the scrub deck out from the right
side of the machine. Make sure no wires
or hoses get hung up on the deck as you
remove it.
8. Install the replacement deck, or reinstall
the existing deck following the reverse
order of the previous steps.
9. Make sure to secure the wiring harnesses
out of the way with cable ties.
2A
2
1B
1C
1D
1D
