FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Leased Line Services
Issue: 13 3HH-11985-AAAA-TQZZA 149
Flags Specifies the conditions that affect the operating status of this SAP.
Display output includes: ServiceAdminDown, SapAdminDown, InterfaceAdminDown,
PortOperDown, PortMTUTooSmall, L2OperDown, SapIngressQoSMismatch,
SapEgressQoSMismatch,RelearnLimitExceeded, RxProtSrcMac, ParentIfAdminDown,
NoSapIpipeCeIpAddr, TodResourceUnavail, TodMssResourceUnavail,
SapParamMismatch, CemSapNoEcidOrMacAddr, StandByForMcRing,
ServiceMTUTooSmall, SapIngressNamedPoolMismatch,
SapEgressNamedPoolMismatch, NoSapEpipeRingNode, mcStandby (22), mhStandby
(23), oamDownMepFault (24), oamUpMepFault (25), ethTunTagMisconfig (26),
ingressPolicerMismatch (27), egressPolicerMismatch (28), sapTl
SAP Count The number of SAPs specified for this service.
SDP Bind Count The number of SDPs bound to this service.
Split Horizon Group specifics
Split Horizon Group Name of the split horizon group for this VPLS.
Description Description of the split horizon group.
Last Changed The date and time of the most recent management-initiated change to this split horizon
group.
Service Destination Points (SDPs)
SDP Id The SDP identifier.
Type Indicates whether this Service SDP binding is a spoke or a mesh.
Admin Path MTU The desired largest service frame size (in octets) that can be transmitted through this
SDP to the far-end router, without requiring the packet to be fragmented.
Oper Path MTU The actual largest service frame size (in octets) that can be transmitted through this SDP
to the far-end router, without requiring the packet to be fragmented.
Delivery Specifies the type of delivery used by the SDP: MPLS.
Admin State The administrative state of this SDP.
Oper State The operational state of this SDP.
Ingress Label The label used by the far-end device to send packets to this device in this service by this
SDP.
Egress Label The label used by this device to send packets to the far-end device in this service by this
SDP.
Far End Specifies the IP address of the remote end of the GRE or MPLS tunnel defined by this
SDP.
Last Changed The date and time of the most recent change to this customer.
Signaling Specifies the signaling protocol used to obtain the ingress and egress labels used in
frames transmitted and received on this SDP.
Admin State Specifies the admin. state of the keepalive protocol.
Oper State Specifies the operational state of the keepalive protocol.
SDP Delivery
Mechanism
A list of static LSPs used to reach the far-end router displays. All the LSPs in the list must
terminate at the IP address specified in the Far End field.
Number of SDPs The total number SDPs applied to this service ID.
Service Access Points
Label Description
(2 of 4)
