FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Private LAN Service
Issue: 13 3HH-11985-AAAA-TQZZA 235
*A:PE6>config>service>vpls# info
----------------------------------------------
bgp
route-distinguisher 65535:100
route-target export target:65535:100 import target:65535:100
pw-template-bind 1
exit
bgp-ad
vpls-id 65535:100
vsi-id
prefix 1.1.1.6
no shutdown
exit
sap 1/1/20:600.* create
exit
no shutdown
----------------------------------------------
*A:PE6>config>service>vpls#
In many cases, VPLS connectivity is based on a pseudowire mesh. To reduce the
configuration requirement, the BGP values can be automatically generated using the
VPLS-ID and the MPLS router-ID. By default, the lower six bytes of the VPLS-ID are
used to generate the RD and the RT values. The VSI-ID value is generated from the
MPLS router-ID. All of these parameters are configurable and can be coded to suit
requirements and build different topologies. The BGP-AD CLI Command Tree is
described in Table 114.
Table 114 BGP-AD CLI Command Tree
A helpful command displays the service information, the BGP parameters and the
SDP bindings in use as demonstrated in Tables 115 and 116. When the discovery
process is completed successfully each endpoint will have an entry for the service.
Table 115 BGP parameters and SDP bindings in use example display:
PE134
leg:isadmin>conf>service>vpls>bgp-ad#
[no] shutdown - Administratively enable/disable BGP auto-discovery
vpls-id - Configure VPLS-ID
vsi-id + Configure VSI-ID
PE134># show service l2-route-table
Services: L2 Route Information — Summary Service
Svc Id L2-Routes (RD-Prefix)
Sdp Bind Id
Next Hop Origin
100 65535:100-1.1.1.6
17406:4294967295
1.1.1.6 BGP-L2
No. of L2 Route Entries: 1
