Table 693 Port And Encapsulation Type Values
Parameters sap sap-id — Specifies the physical port identifier portion of the SAP definition.
Values: [port-id | lag-id] vlanid | no-tag
• port-id
Specifies the physical port ID in the following format:
<port-id> : <nwport-id | ltport-id>
nwport-id - <slot-address>:<port-type>:<port-num>
— slot-address - nt|nt-a|nt-b|ntio-1
— port-type - sfp | xfp |vp | eth | ieee1588 | AI
— port-num - port-number
ltport-id - lt:<rack>/<shelf>/<slot>
— lt - keyword
— rack - number identifying the rack
— shelf - number identifying the shelf
— slot - number identifying the slot
• lag-id
lag: keyword
id: 1 — 64
• vlanid
Specifies the VLAN ID to be associated with the port identified by the SAP.
Values: 0 — 4093
The values depends on the encapsulation type configured for the interface. Table 693
describes the allowed values for the port and encapsulation types.
Port Type Encap-Type Allowed Values Comments
Ethernet Null 0 The SAP is identified by the port.
Ethernet Dot1q 0 — 4093 The SAP is identified by the 802.1Q
tag on the port. Note that a when
only one non-0 vlanid SAP is
created on a dot1q port, the
associated v-VPLS also accepts
untagged packets on the dot1q
port.
Item Description
(2 of 2)
