Technical Data
8-4
Part 1107600_03
 2014 Nordson Corporation
Conduit Penetration Sizes
A4
PG16
PG-21
PG-16
1/2 NPT
Figure 8‐2 Conduit penetration sizes (melter bottom panel shown)
Wiring Diagram
A wiring diagram is provided on the following pages for your reference as
needed.
