Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-67 P/N 196515 (Revision A)
Information Sheet 2-8-4
Conveyor Operations (Continued)
6. Fluid is dispensed.
The fluid is dispensed onto the workpiece according to a pre-programmed
dispensing pattern. Refer to the FmNT User Guide for programming
details.
7. The workpiece leaves the Dispense Station.
When dispensing is complete, the Stop Pin is disengaged, the Lift Table
lowers, and the workpiece is conveyed to the Post-Dispense Station or out
of the dispensing system.
If the downstream machine is not ready for the workpiece or the process
requires the workpiece to be post-heated, go to Step 8.
If the downstream machine is ready and the process does not require
post-heating, the workpiece is conveyed out of the dispensing system. Go
to Step 9.
8. The workpiece arrives at the Post-dispense Station.
A Stop Pin is engaged to stop workpiece transport.
A Board Sensor detects the workpiece.
The Lift Table rises to hold the workpiece in place.
The workpiece may be heated if required by the application
9. The workpiece is conveyed out of the dispensing system.
The dispensing system communicates with the downstream machine via
the SMEMA connection signaling that it is ready to send a workpiece.
When the dispensing system receives the downstream “machine ready”
signal, the Stop Pin disengages, the Lift Table lowers, and the workpiece
is conveyed out of the dispensing system
