Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 1-4 P/N 196515 (Revision A)
Information Sheet 1-1-2
System Features (Continued)
C. Basic Platform
Model
Features
X-1010 X-1020
Application Surface Mount Flip Chip Underfill, Dam & Fill, Cavity Fill
Recommended
Valve Series
DJ-2000
DV-7000
Dual Valve Combinations (option)
DV-01 through DV-05
DV-07 through DV-09
DJ-2000, DP-3000, DV-7000
Dual Valve Combinations (option)
Needle Sensor None Standard
Height Sensor Retractable Tactile (option) Retractable Tactile (option)
Purge Station Standard Standard
Weigh Station None Standard
Vision System Automatic Pattern Recognition Automatic Pattern Recognition
Camera
Miniature, High Resolution with 12.7-mm
(0.5-inch) Image Size
Miniature, High Resolution with 12.7-mm
(0.5-inch) Image Size
Lighting
Red & Blue Variable Diffuse On-Axis
LED Through Lens
Red & Blue Variable Diffuse On-Axis
LED Through Lens
Conveyor
• Control by Conveyor/Heater
Controller
• SMEMA Compliant
• O-ring Drive
• Motorized Rail Spacing
• Board Edge Clamp and Underboard
Support
• 2 Stations
• Fiber-optic Under-the-Rail Board
Sensors at All Stations
• Over-the-Rail Stop Pins
• Control by Conveyor/Heater
Controller
• SMEMA Compliant
• O-ring Drive
• Motorized Rail Spacing
• 3-Lift Tables Standard for Tooling
Engagement
• 3 Stations
• Fiber-optic Over-the-Rail Board
Sensors at All Stations
• Over-the-Rail Stop Pins
Part Heating None Contact or Impingement Heaters
Needle Heater
Resistive Temperature Detector (RTD)
type with a typical temperature range of
Ambient to 120 °C (50 to 70 °F). For use
with DV and DP Series Dispensing
Valves.
Resistive Temperature Detector (RTD)
type with a typical temperature range of
Ambient to 120 °C (50 to 70 °F). For use
with DV and DP Series Dispensing
Valves.
Computer
System
Celeron PC with 88.9-mm (3.5-in.) floppy
and CD-ROM drives, 307-mm (12.1-in.)
color LCD flat-panel display, ASCII
keyboard, and Ethernet network port.
Celeron PC with 88.9-mm (3.5-in.) floppy
and CD-ROM drives, 307-mm (12.1-in.)
color LCD flat-panel display, ASCII
keyboard, and Ethernet network port.
Software Fluidmove for Windows NT (FmNT). Fluidmove for Windows NT (FmNT).
D. Optional Equipment
1. Dual-Action Dispensing Head
2. SECS-GEM Interface for FmNT
3. Low fluid sensor (magnetic or capacitive)
4. Free-Standing Loader (upstream and downstream)
5. Three Station Substrate Heating (contact or impingement)
