Nordson Asymtek X-1010 User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 1-32 P/N 196515 (Revision A)
Information Sheet 1-7-3
Safety Precautions (Continued)
F. Additional Precautions for Service Personnel
1. Only qualified personnel should be permitted to perform maintenance and
troubleshooting procedures.
2. When performing service or maintenance work on the dispensing system in
areas marked with an Electrical Warning Label make sure to disconnect all
power cords and lock out/tag out equipment as detailed in “Lock Out/Tag
Out AC Power and Pneumatic Pressure” on page 1-12.
3. Before troubleshooting the Pneumatic Module, turn Main Air Regulator off (0
psi) or disconnect Main Air Supply.

Nordson Asymtek X-1010 Specifications

General

Type	Dispenser
Accuracy	±25 µm
Fluid Types	Adhesives, sealants
Z-axis Clearance	Customizable based on configuration
Resolution	1 μm
Dispensing Technology	Positive Displacement
Maximum Dot Size	Varies with application
XY Positioning Accuracy	±25 µm
Z Axis Resolution	1 μm
Machine Dimensions	Varies based on configuration
Weight	Varies based on configuration
Power Requirements	200-240 VAC, 50/60 Hz
