Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-60 P/N 196515 (Revision A)
Exercise Sheet 3-8-11
Reconnecting the DJ-2000
Tools Needed:
3mm hex key
1. Place the bracket mount into the slot of the Z-head.
2. The top of the bracket mount should be approximately 2” down from the top of
the Z-head slot.
3. Place the DJ-2000 onto the valve bracket, and mount it onto the protruding
dowel pins.
4. Insert two hex screws through the setscrew holes in the strip across the back of
the DJ-2000, and use the 3-mm hex key to tighten them into the valve bracket.
5. Connect the solenoid cable to the 14-pin CPC connector. The connector
should snap into place.
6. Connect the fork shaped RTD cable to the white RTD connector.
7. Connect the single-pronged heater cable to the black RCA socket.
8. Connect the black pneumatic hose from the DJ-2000 to the black pneumatic
line (center connector).
9. Connect the Height Sensor cable to the Height Sensor connector on the back
of the dispensing head.
