Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-103 P/N 196515 (Revision A)
Diagram Sheet 2-11-5
Probe-to-Needle Alignment
Probe-to-Needle Alignment
1.78–2.54 mm
(0.07–010 in.
)
Height Sensor
Probe
Needle
1 mm
(0.04 in.)
