Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-117 P/N 196515 (Revision A)
Diagram Sheet 2-13-2
Needle Heater Installation
Needle Heater
Heating Element
Needle Heater
Power Connector
