Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-91 P/N 196515 (Revision A)
• Look for damaged electrical cables.
• Look for disconnected or poorly secured electrical cables.
• Look for obstructions that prevent Lift Tables and Stop Pins
to raise or lower.
• Look for pinched or obstructed pneumatic hoses.
• Look for cuts or disconnected pneumatic hoses.
• Listen for pneumatic leaks (a hissing sound).
Perform the following inspections:
Is mechanical
correction required as
a result of the above
inspections?
Resolve and go to Facility
Power and Air Supply
Verification
Go to Facility Power and
Air Supply Verification
NoYes
• Look for damaged electrical cables.
• Look for disconnected or poorly secured electrical cables.
• Look for obstructions that prevent Lift Tables and Stop Pins
to raise or lower.
• Look for pinched or obstructed pneumatic hoses.
• Look for cuts or disconnected pneumatic hoses.
• Listen for pneumatic leaks (a hissing sound).
Perform the following inspections:
• Look for damaged electrical cables.
• Look for disconnected or poorly secured electrical cables.
• Look for obstructions that prevent Lift Tables and Stop Pins
to raise or lower.
• Look for pinched or obstructed pneumatic hoses.
• Look for cuts or disconnected pneumatic hoses.
• Listen for pneumatic leaks (a hissing sound).
Perform the following inspections:
Is mechanical
correction required as
a result of the above
inspections?
Is mechanical
correction required as
a result of the above
inspections?
Resolve and go to Facility
Power and Air Supply
Verification
Go to Facility Power and
Air Supply Verification
NoYes
Diagram Sheet 4-7-1
Pneumatics Fault Isolation Procedure - Mechanical Verification
