Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-20 P/N 196515 (Revision A)
Diagram Sheet 5-4-3
Removing /Installing the Heater Tooling Plate
Heater Toolin
g
Plate (Contac
t
Heater Shown)
Alignmen
t
Pin
Front Conveyo
r
Rai
l
Vacuum Hose
Lift Table
Heater Power
Cable
