Nordson Asymtek X-1010

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-43 P/N 196515 (Revision A)
Diagram Sheet 5-7-1
Removing/Installing the Main Interface PWA
Hex Post Removal/Installation
Main Interfac
e
Pane
l
Hex Pos
t
(16 total a
s
circled)
D-sub
Connector
(8 total)
Removing/Installing the Main Interface PW
A
Computer Doo
r
Hold-down Scre
w
(3 total)
Main Interfac
e
PWA
Ribbon Cable
