Hopper Assembly
The hopper assembly parts vary depending on the size of the melter:
one/two‐pump, three/four‐pump, or 100L. Refer to the correct parts list for
your melter.
Melter Hopper Parts
See Figure 7‐3.
Item Part Description Quantity Note
— ‐ ‐ ‐ ‐ ‐ ‐ ‐ MODULE, HOPPER —
201 ‐ ‐ ‐ ‐ ‐ ‐ ‐ HOPPER, EZ, 20L 1
‐ ‐ ‐ ‐ ‐ ‐ ‐ HOPPER, EZ, 45L 1
202 7410545 GASKET, HOPPER, EZ, 20L 1
203 ‐ ‐ ‐ ‐ ‐ ‐ ‐ SCR, SKT, M6 X 20, BL 12
204 ‐ ‐ ‐ ‐ ‐ ‐ ‐ WASHER, LK, M, SPT, M6,STL,EZ 12
205 ‐ ‐ ‐ ‐ ‐ ‐ ‐ WASHER, FLT, M, SPT, M6,STL,
EZ
12
206 7410581
SERVICE KIT, HEATER, 240V, 800W, 1/2 X
9.0 L
3
207 ‐ ‐ ‐ ‐ ‐ ‐ ‐ SCR, SKT, M5 X 10, BL 5
209 ‐ ‐ ‐ ‐ ‐ ‐ ‐ WASHER, M6, FLT, SPECIAL BIG, STL, ZP,
GB96
3
210 1024618 THERMOSTAT,OOR,500DEG F,PUSH-ON
TERM
1
211 ‐ ‐ ‐ ‐ ‐ ‐ ‐ WASHER, LK, M, EXT, M4,STL,EZ 2
212 ‐ ‐ ‐ ‐ ‐ ‐ ‐ SCR, SHCS, M4 X 6, BL 2
214 1030564 PLATE, CAPTURE, RTD 1
215 900298 COMPOUND, HEAT SINK,5 OZ TUBE 1
216 7410542 INSULATION,HOPPER,EZ,20L 1
To Next Page
