Parts
7-16
Part 1126931_01
ξ˜ƒ 2018 Nordson Corporation
Electrical Enclosure Panel Assemblies
The electrical enclosure panel assembly parts vary depending on the size of
the melter: one/two‐pump, three/four‐pump, or 100L. Refer to the correct
parts lists for your melter.
Melter Left Panel Parts ‐ 400V
See Figure 7‐11.
Item Part Description Quantity Note
β€” ‐ ‐ ‐ ‐ ‐ ‐ ‐ 400V ASSEMBLY, ELECTRICAL, PANEL, LEFT,
ONE/TWO‐PUMP
β€”
1 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ PLATE ASSY,ELEC CABINET,LEFT,EZ 1
2 7411712 ξ˜„ CIRCUIT BREAKER 32A 1‐POLE 4
3 7411708 ξ˜„ BOARD,BREAKOUT,RSMA-20D0CD,TB,20POS,
EZ
1
4 7411710 ξ˜„ CIRCUIT BREAKER 50A 3‐POLES 1
5 7411711 ξ˜„ CONTACTOR, 40A 1
6 7410952 ξ˜„ RELAY, DC 24V 1
7 777630 ξ˜„ BASE, RELAY (OMRON) 1
8 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ CLIP,RELAY 2
9 207396 ξ˜„ SOLID-STATE RELAY, G3PE 100-260V MAX. 15A 4
10 7400070 ξ˜„ SOLID STATE RELAY,100-260VAC,35A,DC TRIG 2
11 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK POWER 400V WYE 1
12 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK, ZDU 16 4
13 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK, ZPE 16 1
14 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK, END PLATE, ZAP/TW, ZDU 16 1
15 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK, ZDU, 2.5 20
16 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ EW35 12
17 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL BLOCK, END PLATE ZAP/TW1 5
18 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ TERMINAL CONNECTOR, ZQV2, 5/2 3
19 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ξ˜„ HEXNUT, FLANGED, SERRATED, M5 2
