Nortek Signature Series User Manual

Integrator's Guide22
© 2017 Nortek AS
Command
Description
Scope
TRIG
Used for trigging measurement when Trigger is
enabled and trigger type equals “COMMAND”
Measurement mode
GETPWR
Returns the amount of power the various modes will
consume in mWatts
Command mode
GETPRECISION/
GETPRECISION1
Returns the precision along beam and horizontally
for the various velocity profiles
Command mode
SETUSER/
GETUSER
Set/Get User Settings
Command mode
GETHW
Returns Firmware versions and Board revisions.
All modes
ID
Returns system name and ID number
Command mode
SETDEFAULT
Reload default settings.
Command mode
SAVE
Save current settings for next measurement.
Command mode
DEPLOY
Deploy the instrument
Command mode
FWRITE
Write tag/String to file.
Command mode,
Confirmation mode, Data
retrieval mode
POWERDOWN
Go in power down.
Command mode
ERASE
Erase the recorder
Command mode
FORMAT
Format the recorder
Command mode
SECREBOOT
Reboot the SEC (Interface processor)
Command mode
LISTFILES
Lists the files stored on the Instrument recorder.
Command mode, Data
retrieval mode
DOWNLOAD
Enables reading a file at the instrument recorder.
Command mode, Data
retrieval mode
INQ
Inquires the instrument state
All modes
GETSTATE
Returns information about the current operational
state of the instrument
All modes
GETERROR
Retrieves a full description of the last error condition
to occur
All modes
GETALL
Retrieves all relevant configuration information for the
instrument.
Command mode
RECSTAT
Returns Recorder Statistics
Command mode, Data
retrieval mode
GETMISCLIM
Returns configuration limits that cannot be returned
through the relevant commands
Command mode
GETXFAVG/
GETXFBURST
Returns the “Beam to XYZ” transfer matrix for the
current setup.
Command mode
ADDLINE
Command mode
SETTMAVG/
Set/Get Averaging Mode Telemetry Settings
Command mode

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
