6-16
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Table 6-2 lists the required options for a 672-line cabinet.
Table 6-3 lists the standard equipment for an expansion kit from 672- to
864-line cabinet. For the equipment frame/bay layouts and mounting
positions, see Figure 6-7.
P0805660 Cable assembly used on NT6C28FB-61 2
NTNR93AA Rectifier dc power cable assembly 2
NTNR93BA Rectifier ground wire assembly 1
P0832887 DC distribution shelf mounting bracket 2
P0835511 Cable assembly 2
Cables, assemblies and kits to order
NTNR90AA Distribution power cable used to power up the CDS shelves 1
NTNR90BA Cable kit to power up the CDS shelves 1-7 talk batteries 1
—end—
Table 6-2
AN2016 Cabinet 672-line required options
CPC PEC Description Quantity
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 2 or 3
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Order (1) MPR 25 for each AN hardware (672L) + (1) for each OEM stack + (1) for redundancy.
Note 3:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Table 6-3
672- to 864-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
NTNR10AA includes AccessNode hardware kit 1
Note:
A second ABM is required to support the additional CDS shelves.
NT4K14AB Breaker interface panel 1
NT4K1490 Breaker interface front cover assembly 1
NT4K16CA Local craft access panel, modular business package 1
—continued—
Table 6-1 (continued)
AN2016 Cabinet 672-line equipment (standard)
PEC Description Quantity
