Ordering information
6-33
User Guide Rel 1.0 Standard May 1999
Table 6-11 lists the required options for a 1344-line cabinet.
NT5C10CP-61 Rectifier shelf for system 200, gray 2
NT5C10KC AC fail assembly 2
P0805660 Cable assembly used on NT6C28FB-61 2
NTNR93AA Rectifier dc power cable assembly 2
NTNR93BA Rectifier ground wire assembly 1
P0832887 DC distribution shelf mounting bracket 2
P0835511 Cable assembly 2
Cables, assemblies and kits to order
NTNR91AB BIP # 2 power cable assembly 1
NT7E44JC CNet bay cable provides communication links between ABM
shelves
1
NTNR80AA 14 pair cable assembly provides DS1 connectivity between
AccessNode and DSX panel
2
NTNR80BA 28 pair cable assembly provides DS1 connectivity between
AccessNode and DSX panel
2
NTNR90AA Distribution power cable used to power up the CDS shelves 2
NTNR90BA Cable kit to power up the CDS shelves 1-7 talk batteries 2
—end—
Table 6-11
AN2016 Cabinet 1344-line required options
CPC PEC Description Quantity
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 3 or 4
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Order (1) MPR 25 for each AN hardware (672L) + (1) for each OEM stack + (1) for redundancy.
Note 3:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Note 4:
Refer to “ Optional remote monitoring unit” on page 6-44 for ordering RMU test access path
cable when optional RMU NTNR35AA is selected. A cable must be ordered for each additional AN ABM
NTNR10AA.
Table 6-10 (continued)
AN2016 Cabinet 1344-line equipment (standard)
PEC Description Quantity
To Next Page
