Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Table 6-12 lists the standard equipment for an expansion kit from 1344- to
2016-line cabinet. For the equipment frame/bay layouts and mounting
positions, see Figure 6-10, Figure 6-11 and Figure 6-12.
Table 6-12
1344- to 2016-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
NTNR10AA includes AccessNode hardware kit 1
Note:
A second ABM is required to support the additional CDS shelves.
NT4K14AB Breaker interface panel 1
NT4K1490 Breaker interface front cover assembly 1
NT4K16CA Local craft access panel, modular business package 1
NT4K10AB Access common equipment shelf 1
NT4K1033 ABM front shelf cover 1
NT4K0610 Fan shelf assembly, eight fans 1
P0846202 Fan shelf assembly cover 1
NT4K84BA Power cable common equipment 2
NT4K1024 ABM english label kit 1
NT4K1422 Breaker interface panel english label kit 1
P0732671 Product label identification 1
NT4K85JB Termination, cooling unit interface 1
NT4K85KA BIP control cable assembly 1
A0630076 Circuit breaker 30 A 80 V dc 4
NTNR13AA includes Copper distribution shelf kit for 2016 line 1
NT4K12AB Copper distribution shelf 7
NT4K1222 Line shelf label kit 7
NT4K82DA Cable assembly, A/B link VF/T/D, CDS 1 1
NT4K82DB Cable assembly, A/B link VF/T/D, CDS 2 1
NT4K82DC Cable assembly, A/B link VF/T/D, CDS 3 1
NT4K86NA Shelf metallic test pair cable assembly, 2 ft long 5
NT4K0610 Fan shelf assembly, eight fans 2
