 ,QVWDOODWLRQ Wiring a Signaling Line Circuit (SLC)
2-40 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
6/&'HYLFHV
1RWH 0D[LPXP ZLULQJ GLV WDQFH
RI DQ 6/& ORRS
6W\OH   IW  $:*
6W\OH    IW  $:*
WRWDO WZLVWHGSDLU
Communication with intelligent and addressable initiating, monitor, and control devices
takes place through a Signaling Line Circuit (SLC). You can wire an SLC to meet the
requirements of NFPA Style 4, Style 6, or Style 7 circuits. Table 2-16 contains
descriptions of devices connected to an SLC:
Table 2-16 SLC Devices
&RQWURO3DQHO&DSDFLW\
1RWH 5HIHU WR WKH LQVWDOODWLRQ
GUDZLQJV VXSSOLHG ZLWK HDFK
ORRS GHYLFH IRU UDWLQJ DQG
VSHFLILFDWLRQ LQIRUPDWLRQ
Each control panel has the capacity to support the following:
$)3
99 intelligent detectors, 99 monitor/control modules, and up to 68 internal
circuits/relays as shown in Figure 2-54:
)LJXUH  $)3 &DSDFLW\
$)3
up to 198 intelligent detectors, and an additional combination of up to 198
addressable pull stations, control modules and monitor modules; and up to 68 internal
circuits/relays as shown in Figure 2-55:
)LJXUH  $)3 &DSDFLW\
Type of Device SLC Function
Isolator Modules
(ISO-X)
Allows a zone of detectors and modules to be electrically isolated from
the remainder of the loop, which lets critical loop components function
if a circuit fails. ISO-X modules are required for NFPA Style 7 circuits.
Addressable
Monitor Modules
(MMX series)
Allows the control panel to monitor entire circuits of conventional,
alarm initiating devices, such as manual pull stations, detectors,
waterflow and supervisory devices. The BGX-101L (a type of monitor
module) provides point annunciation of manual pull stations.
Control Modules
(CMX series)
Allows the control panel to selectively activate Notification Appliance
Circuits (NACs) or Form-C output relays.
Intelligent
Detectors
Allows the control panel to communicate with intelligent ionization,
photoelectric, and thermal detectors on the loop.
6/& ² 8S WR  LQWHOOLJHQW
DGGUHVVDEOH GHYLFHV
6/&  ² 8S WR  LQWHOOLJHQW
DGGUHVVDEOH GHYLFHV
6/&²8SWRLQWHOOLJHQW
DGGUHVVDEOH GHYLFHV
