mstconfig Commands
mstconfig Backup Command
The backup command is used to save the current non-volatile configurations (TLV) in the deviceinto a
file in raw TLV syntax so it can be restored anytime using the set_raw command.
mstconfig backup command allows backing up the all of the configurations which are relatedonly to
the PCI Physical Function associated with the given MST device. To back up all of thedevice
configurations, perform the operation from every PCI Physical Function the deviceexposes. Restoring
the configurations must be made from the matching PCI Physical Function.
# mstconfig -d 41:00.0 -f /tmp/backup.conf backup
Collecting...
Saving output...
Done!
# cat /tmp/backup.conf
MLNX_RAW_TLV_FILE
% TLV Type: 0x00000400, Writer ID: ICMD mstCONFIG(0x09), Writer Host ID: 0x00
0x00000014 0x00000400 0x00000000 0x00000000 0x000e0000 0x001000f6 0x20160526
0x11250000
# mstconfig -d 41:00.0 -f /tmp/backup.conf set_raw
Raw TLV #1 Info:
Length: 0x14
Version: 0
OverrideEn: 0
Type: 0x00000400
Data: 0x00000000 0x000e0000 0x001000f6 0x20160526 0x11250000
Operation intended for advanced users.
Are you sure you want to apply raw TLV file? ? (y/n) [n] : y
Applying... Done!
-I- Please reboot machine to load new configurations.
Generating an XML Template for the Configurations
Users can generate an XML file that contains a template for the configurations. The templatedescribes
the configurations and their parameters. No values are included in the template.
To generate such a template, run the gen_tlvs_file command. This command will generate a
filecontaining a list of all supported configurations by mstconfig, with a zero appearing in the end
ofeach configuration. To choose a configuration, change the 0 to 1, then save the file and run
thegen_xml_template command. An XML file containing the required configurations will begenerated.
Example:
# mstconfig gen_tlvs_file /tmp/confs.txt
Saving output...
Done!
# cat /tmp/confs.txt
nv_host_to_bmc 0
nv_kdnet_data 0
nv_fpga_data 0
nv_packet_pacing 0
nv_debug_mode 0
nv_global_pci_conf 0
In a MultiHost environment, these operations are required to be executed per host.

