Nvidia MSTFLINT User Manual

33
•
•
•
•
•
•
Feature Parameter Values
PF_BAR2_ENABLE
Enables the physical function bar size.
Values: Unsigned numerical
values
PF_BAR2_SIZE
Sets the physical function bar size.
Values: Unsigned numerical
values
IB Dynamically Connect
1
:
Configure the number of
allocated local DC
resources (DCR)
DCR_LIFO_SIZE
The amount of total DCRs available to
join linked-lists after hash DCRs
0 to 16777215 (maximal size may
be smaller depending on the
firmware)
LOG_DCR_HASH_TABLE_SIZE
Log2 of the hash table size minus 1
0 to 31 (maximal size may be
smaller depending on the
firmware)
InfiniBand Boot
Settings: Sets the
partition key to be used
by PXE boot
4th Generation Parameters:
BOOT_PKEY_P1
BOOT_PKEY_P2
5th Generation Parameters:
BOOT_PKEY
Partition key to be used by PXE boot
0-65535
0: Default
Internal Settings
1
:
Configures internal
settings of the HCA
INT_LOG_MAX_PAYLOAD_SIZE
log2 of the maximal burst
length when accessing PCI translation
table
_4KB: 4KB burst length
AUTOMATIC: Default
Preboot Boot Settings:
Settings that control the
legacy option ROM
4th Generation Parameters:
BOOT_VLAN_EN_P1
BOOT_VLAN_EN_P2
5th Generation Parameters:
BOOT_VLAN_EN
Disable/Enable VLAN mode for
network boot
False: Disable
True: Enable
BOOT_RETRY_CNT
Number of retries to attempt in case of
boot failure from port1/2.
0 to 7
7: infinite retries
LEGACY_BOOT_PROTOCOL_P1
LEGACY_BOOT_PROTOCOL_P2
Boot protocol for port1/2
None: None - disable legacy boot
PXE: PXE (DHCP/TFTP boot)
iSCSI: iSCSI
Both: PXE + iSCSI
