Nvidia MSTFLINT User Manual

35
Feature Parameter Values
CLAMP_TGT_RATE_P1
CLAMP_TGT_RATE_P2
If set, whenever a CNP is processed,
the target rate is updated to be the
current rate
False: Disable
True: Enable
CNP_DSCP_P1
CNP_DSCP_P2
The DiffServ Code Point of the
generated CNP for port1/2
0 to 63
0: Default
CNP_802P_PRIO_P1
CNP_802P_PRIO_P2
The 802.1p priority value of the
generated CNP for port1/2
0 to 7
7: Default
DCE_TCP_G_P1
DCE_TCP_G_P2
Used to update the congestion
estimator (alpha) once every
DCE_TCP_RTT microseconds for the
selected port
0 to 1023
64: Default
DCE_TCP_RTT_P1
DCE_TCP_RTT_P2
The time between updates of the alpha
value per port, in microseconds
0 to 131071
2: Default
INITIAL_ALPHA_VALUE_P1
INITIAL_ALPHA_VALUE_P2
The initial value of alpha to use when
receiving the first CNP for a flow.
Expressed in a fixed point fraction of
2^10
0 to 1023
MIN_TIME_BETWEEN_CNPS_P1
MIN_TIME_BETWEEN_CNPS_P2
Minimum time between sending cnps
from the port, in microseconds
0 to 131071
0: Default
RATE_TO_SET_ON_FIRST_CNP_P1
RATE_TO_SET_ON_FIRST_CNP_P2
The rate that is set for the flow when a
rate limiter is allocated to it upon first
CNP received, in Mbps
0 to 131071
0: Default
