Page #89 background image
89
--serdes_tx <params> Configure Transmitter Parameters
[polarity,ob_tap0,...]
--serdes_tx_lane <transmitter_lane> Transmitter Lane to Set (Optional - Default All
Lanes)
--database Save Transmitter Configuration for Current Speed
Permanently (Optional)
--test_mode <prbs_mode> Physical Test Mode Configuration [EN(enable)/
DS(disable)/TU(perform tuning)]
--rx_prbs <rx_prbs_mode> RX PRBS Mode [PRBS31(Default)/PRBS7/...]
(Optional - Default PRBS31)
--tx_prbs <tx_prbs_mode> TX PRBS Mode [PRBS31(Default)/PRBS7/...]
(Optional - Default PRBS31)
--rx_rate <rx_lane_rate> RX Lane Rate [EDR(Default)/25G/10G/...] (Optional -
Default 25G)
--tx_rate <tx_lane_rate> TX Lane Rate [EDR(Default)/25G/10G/...] (Optional -
Default 25G)
-b |--ber_collect <csv_file> Port Extended Information Collection [CSV File]
--ber_limit <limit_criteria> BER Limit Criteria [Nominal(Default)/Corner/Drift]
(Optional - Default Nominal)
--iteration <iteration> Iteration Number of BER Collection
--pc Clear Counters
--set_external_phy Set External PHY
--twisted_pair_force_mode
<twisted_pair_force_mode>
Twisted Pair Force Mode [MA(Master)/SL(Slave)]
Examples:
Get info of <device>, <port_number>:
mstlink -d <device> -p <port_number>
Get info of <device>, <port_number> and BER Counters:
mstlink -d <device> -p <port_number> -c
Get info of <device>, <port_number> and Transmitter Parameters:
mstlink -d <device> -p <port_number> --show_serdes_tx
Configure Port State:
mstlink -d <device> -p <port_number> --port_state UP
Configure Port Speeds:
mstlink -d <device> -p <port_number> --speeds 25G,50G,100G
