Oki Data CONFIDENTIAL
42930511TH Rev. 2 148 /
NV-RAM INITIAL
INITIAL 1
5.1.2.6 Initialize NVM
This self-diagnosis is used to initialize the nonvolatile memory.
1. Continue to press the [MENU+] and [MENU-] keys until “NV-RAM INITIAL” appears at the
top row of the display, and the system is in the self-diagnosis (Level 1) mode. The [MENU+]
key = Increment Test Item / the [MENU-] key = Decrement Test Item.
2. When the [ENTER] key is pressed, the Table No. to be initialized appears at the bottom
row of the display. There are 3 tables initialized. Press the [MENU+] and [MENU-] keys
until the applicable Table No. appears. The [MENU+] key = Increment Table No. / the
[MENU-] key= Decrement Table No.
Do not use INITIAL 2.
3. When the [ENTER] key is pressed, the “NV-RAM INITIAL” display blinks at the top row
of the display. Press it for 10 consecutive seconds to initialize all items indicated in Table
5-3.
4. Press the [BACK] key to end the test. (Returns to state 1)
Note
Table 5-3 NV-RAM Initial
Item to Initialize
K-DRUM UNIT
Y-DRUM UNIT
M-DRUM UNIT
C-DRUM UNIT
FUSER UNIT
TR BELT UNIT
K-DISTNR
Y-DISTNR
M-DISTNR
C-DISTNR
DISTNR CNT
DISTNR BOX TNR CNT
Detail
Total number of revolutions since the ID unit for each
color has been installed.
Total number of revolutions since the fuser unit has
been installed.
Total number of revolutions since the belt unit has
been installed.
Quantity of each color of toner to be discarded
Quantity of toner discarded in toner disposal
Quantity of toner discarded in toner disposal or for
correction (e.g., color cast, color misregistration, and
density)
Unit
IMAGES
IMAGES
IMAGES
IMAGES
PRINTS
IMAGES
-
-
-
-
-
-
Initial Setting
0
0
0
0
0
0
0
0
0
0
0
0
To Next Page
