Oki C9600 Service Manual

Oki Data CONFIDENTIAL
42930511TH Rev. 2 149 /
5.1.2.7 Consummable Parts Counter Display
This self-diagnosis is used to display the consumption status of the consumable parts of the printer.
1. It will go into normal self-diagnosis. Continue to press the [MENU+] and [MENU-] keys
until “CONSUMABLE STATUS” appears at the top row of the display. (The [MENU+] key
to Increment the Test Item / the [MENU-] key to decrement the Test Item.)
2. After the [ENTER] key is pressed, press the [MENU+] and [MENU-] keys to sequentially
display the consumption status according to consumable part.
3. Press the [BACK] key to end the test. (Returns to state 1)
5.1.2.8 Consumable Continual Counter Display
This self-diagnosis is used to display the consumption status of the consumable parts of the printer.
The life consumption status of consumable parts means that the counter value is not initialized though
the consumable parts are replaced. It is a way to continually count the consumption level of the
consumable parts of the printer.
1. It will go into normal self-diagnosis. Continue to press the [MENU+] and [MENU-] keys
until “PRINTER STATUS” appears at the top row of the display. (The [MENU+] key to
Increment the Test Item / the [MENU-] key to decrement the Test Item.)
2. After the [ENTER] key is pressed, press the [MENU+] and [MENU-] keys to sequentially
display the life consumption status according to consumable part.
3. Press the [BACK] key to end the test. (Returns to state 1)
Top of the Display
K-DRUM UNIT
Y-DRUM UNIT
M-DRUM UNIT
C-DRUM UNIT
FUSER UNIT
TR BELT UNIT
K-TONER
Y-TONER
M-TONER
C-TONER
STAPLE UNIT
PUNCH UNIT
PATTING ROLLER
STAPLE CONSUMPTION
STAPLE UNIT REPLACE
PUNCH UNIT REPLACE
Detail
Indicates the total number of revolutions since the ID unit for
each color has been installed.
Indicates how many pages have been printed since the fuser
unit has been installed.
Indicates how many pages have been printed since the belt unit
has been installed.
Indicates what quantity of each color of toner has been consumed.
* Indicates 90% when the toner level is low.
Indicates how many times stapling has been performed.
Indicates how many times punching has been performed.
Indicates how many sheets have passed by the patting roller.
Indicates how many staples have been used.
* The count is reset when staples are refilled.
Indicates how many times the staple unit has been replaced.
Indicates how many times the punch unit has been replaced.
Bottom of the Display
****** IMAGES
****** PRINTS
****** IMAGES
***%
****** JOBS
****** PRINTS
****** PRINTS
****** PIECES
****** TIMES
****** TIMES
Format
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
Top of the Display
K-IMPRESSIONS
Y-IMPRESSIONS
M-IMPRESSIONS
C-IMPRESSIONS
TOTAL SHEETS FEED
FINISHER TOTAL PAGE
Detail
Indicates how many pages have been printed using each color.
Indicates the total number of sheets fed.
Indicates the total number of sheets having passed by the finisher.
Bottom of the Display
****** PRINTS
****** PRINTS
****** PRINTS
Format
DEC
DEC
DEC
