Oki Data CONFIDENTIAL
42930511TH Rev. 2 203 /
3 Blank Sheet (Figure 7-2
C
)
• Are all LED head Assy parts properly connected to the relay PCB (S2H PWB) and engine PCB
(S2V PWB)?
NO Check the cable connection of the LED head and cable connection between
between the relay PCB and engine PCB, then properly connect the cable
between the LED head and engine PCB.
• YES Is the LED head pressing spring properly set?
NO Properly set the pressing spring.
• YES Are the protrusions on both sides of the LED head properly in contact with each
FG plate spring?
NO Correct the bend in the FG plate spring.
• YES Replace the LED head.
Has the problem been corrected?
YES END
• NO Replace the engine PCB (S2V PWB).
Has the problem been corrected?
YES END
• NO Replace the head shield cable.
Has the problem been corrected?
YES END
• NO Check the cable connection, then replace the low voltage power unit.
Has the problem been corrected?
YES END
• NO Is +20V or more output to the Pin 16 of the HVOLT connector on the Engine
PCB (S2V PWB)?
NO Replace the engine PCB.
• YES Check the cable connection, then replace the high voltage power unit or belt unit.
Has operation been restored?
YES END
• NO Is the I/D unit terminal properly connected to the contact Assy?
(Refer to Figure 7-3)
NO Properly connect the I/D unit terminal to the contact Assy.
• YES Replace Image Drum Unit.
1. When replacing the Engine PCB (S2V PWB), remove the EEPROM from the old PCB,
then mount that EEPROM on the new PCB.
2. If the EEPROM is not going to be replaced, refer to Section 5.2.2.
Note
To Next Page
