14 Technical specifications
The following technical indications are medial values. During operation small variations are quite
possible. Technical changes due to development are possible!
2.1 Control unit
Dimensions (H x W x D) .............................................................................................. 180 x 230 x 120 mm
Weight .................................................................................................................................. approx. 1.2 kg
Protection Class ................................................................................................................................... IP40
Operating time (internal battery) ..................................................................................... approx. 24 hours
Charging time (internal battery) ........................................................................................ approx. 3 hours
Input (charger socket) ...................................................................... 19 VDC / 0.6 A (max. 24 VDC / 0.5 A)
Operating time (optional Power Pack) .............................................................................. approx. 48 hours
Input (optional Power Pack) ........................................................... 12.5 VDC / 0.9 A (max. 24 VDC / 0.5 A)
Processor / Main CPU .................................................................................................. Cortex M3, 32 MHz
Processor / Slave CPU ................................................................................................. Cortex M0, 24 MHz
Display .............................................................................................. 3.5” Resistive touch, 480 x 320 Pixel
Display CPU ........................................................................................... Cortex M3, 32 MHz, 128 KB RAM
Data memory ....................................................................................................................................... 4 GB
Sample rate ................................................................................................................ 1024 values / second
Measurement resolution .................................................................................................................... 16 bit
Operating temperature .............................................................................................................. -10 – 60 °C
Storage temperature ................................................................................................................. -20 – 70 °C
Audio .............................................................................................................. Internal speaker / Bluetooth
Air humidity ............................................................................................................................... 5 % – 75 %
Waterproof ............................................................................................................................................. No
2.2 Wireless data transfer
Technology .................................................................................................................................. Bluetooth
Frequency range .............................................................................................................. 2.4 – 2.4835 GHz
Maximum transfer rate ................................................................................................................... 1 Mbps
Receiving sensitivity ...................................................................................................................... -85 dBm
Maximum range ........................................................................................................................ about 10 m
2.3 Super Sensor
Length ............................................................................................................................................ 850 mm
Diameter, Shaft / LED Orbit ............................................................................................... 50 mm / 65 mm
Weight ............................................................................................................................................. 0.85 kg
Sensor technology ..................................................................................................................... SCMI-15-D
