OKM Future Series - Breakdown of the Ground Navigator; Figure 5.1: 3 D Ground Navigator with Control Unit and Super Sensor

28 Control elements
5.1 Breakdown of the Ground Navigator
The key components to the 3D Ground Navigator are shown below.
The Control Unit is the operating center and processing unit of the whole detector system. You will
select your appropriate operating mode and adjust all settings to scan your area.
The Super Sensor measures the environment and transfers all data to the control unit for further
processing. The Super Sensor comes with a LED orbit to visualize detected objects.
If the control unit is connected with Wireless Headphones it will turn off the internal speaker.
For much longer operating times an optional Power Pack can be utilized with the detector.
OKM GmbH
www.okmmetaldetectors.com
Figure 5.1: 3D Ground Navigator with control unit and Super Sensor
Wireless
Headphones
Power Pack
(optional)
Control Unit
Super Sensor
with LED orbit
