On this same menu, the program is shown on the right side of the CRT. The line identified by
the arrow-up mark ( ) is the block being executed. The right arrow symbol ( ) indicates the
blocks read and stored into the buffer.
Pressing the “Page Down” key will show the machine state and load display menu. This page
shows the following additional information.
M Spindle gear range
V Surface cutting speed
The right side of the CRT shows the load status of the spindle, X and Z axes.
Another menu in the Actual position mode shows the following information.
Program Actual position data
Distance Remaining axis travel amount of the individual axes
Shift Shows the actual position value from the zero offset
Machine Shows the raw data coming from the absolute position encoder (RCON)
Tool Offset Shows the active tool offset amounts
Pitch Shows the pitch error compensation data when applicable
Machining Center
The following is a description of the data shown in the individual menus of the Actual Position
mode on a 5000/5020M series control.
X X axis position
Y Y axis position
Z Z axis position
B B axis position in degrees
CO Work coordinate system number
F Actual feedrate
S Actual Spindle speed
H= Tool length offset number
D= Cutter radius compensation number
O Currently active subprogram name
N Sequence number (block number)
Gear Spindle drive gear condition
Touch
Sensor Reverse display indicates the Touch Sensor is on.
Touch
Probe Reverse display indicates the Touch Probe is on.
The Load Status display screen on the right side of this display screen shows the load conditions
of the spindle and individual axes.
