BLOCK DATA
By using the PAGE key on the NC operation Panel, various screens can be accessed after the
BLOCK DATA function key has been pressed. The following bullets describe what the different
screens show:
• Displays the data in the block currently being executed.
• Displays the data in the NEXT block to be executed.
• Displays the data in the block succeeding (QUEUED) the next block.
• Displays the data last stored in the buffer (READ) register.
CHECK DATA
By using the PAGE key on the NC operation Panel, various screens can be accessed after the
CHECK DATA function key has been pressed. The following bullets describe what the different
screens show:
• Displays servo data related to individual axes.
• Displays EC inputs (machine side inputs).
• Displays EC outputs
• Displays Machine Operation Panel inputs.
• Displays Machine Operation Panel outputs.
• Displays machine’s specification codes.
• Displays machine’s model code.
• Displays machine’s machine specification codes.
• Displays history of alarms (last 12 alarms).
• Displays ATC I/O’s (if applicable).
• Displays post process gauging data (if applicable).
• Displays in process gauging data (if applicable).
PROGRAM
