Okuma OSP 5000 - Operational Panel above Tape Reader View

To Next Page

To Previous Page

4-38

Okuma America Corporation

MACHINE OPERAMACHINE OPERA

MACHINE OPERA

TIONTION

TION

Rev. 8-21-01

0 1 2 3 4 116

HOUR METER

EMG STOP

RESET

READY EMG STOP

POWER ON

POWER OFF

ERROR

LIGHT

AUTO POWER

OFF

OPERATION END MODE

BUZZER LIGHT

PUNCHER

SERIAL

AC100V

PARALLEL

OPTIONAL

Operational Panel above Tape Reader

Main Page
