Access Address (MB II B)
Address Board and Card Address Board and Card *1
000000 - 07FFFF Main card 11 (first) or 12 (first) F00000 - F1FFFF ECP board II and Card 1-II (volatile RAM)
080000 - 0FFFFF Main card 11 (second) or 12 (first) F20000 - F77FFF Not-used area
100000 - 17FFFF Main card 11 (third) or 12 (first) F78000 - F7BFFF ECP board II and card 1-II (non-volatile RAM)
180000 - 1FFFFF Main card 12 (first) F7C000 - F7CFFF Main card 2 (panel 1F)
200000 - 3FFFFF Main card 12 (second) or (first) F7D000 - F7DE3F Not-used area
400000 - 5FFFFF Main card 12 (third) or (first) F7DE40 - F7DE5F ECP card 4-II
600000 - 7FFFFF Not-used area F7DE60 - F7DEF7 ECP card 3 (PG, EC I/O)
800000 - 8FFFFF Main card 10 F7DE80 - F7DEBF Main card 3 (RS232C)
900000 - AFFFFF Not-used area F7DECO - F7DEDF Main card 3 (puncher, centronics)
800000 - BOFFFF Main board IIB F7DEE0 - F7DEFF ECP card 2 (EC I/O)
B10000 - CFFFFF Not-used area F7DF00 - F7DF3F Not-used area
D00000 - D1FFFF CCP board or CCP card (eighth) F7DF40 - F7DF5F ECP card 4-II
D20000 - D3FFFF CCP board or CCP card (seventh) F7DF60 - F7DF9F Not-used area
D40000 - D5FFFF CCP board or CCP card (sixth) F7DFA0 - F7DFBF Main card 2-II of main card 2, 4
D60000 - D7FFFF CCP board or CCP card (fifth) F7DFCO - F7DFFF Not-used area
D80000 - D9FFFF CCP board or CCP card (fourth) F7E000 - F7FCFF User-inhibited area
DA0000 - DBFFFF CCP board or CCP card (third) F7FD00 - F7FFFF ECP board II(D/A, R1C, encoder, ECBUS)
DC0000 - DDFFFF CCP card (second)
DE0000 - DFFFFF CCP board or CCP card (first)
Address Board and card *2
E00000 - E77FFF Not-used area FFD000 - FFD05F IJP card 3
E78000 - E7FFFF CRP board 9 FFD060 - FFDO7F IJP card 5
E80000 - EFFFFF ECP board II 9 (second) FFD080 - FFD09F IJP card 6
F00000 - F7FFFF ECP board II (first) FFD0A0 - FFD0BF Not-used area
F800000 - F87FFF SVP board II (first) FFD0C0 - FFD0FF Main card 14
F88000 - F8FFFF SVP board II (second) FFD100 - FFDCFF Not-used area
F90000 - F97FFF SVP board II (third) FFDD00 - FFDE1F Main board IIB
F98000 - F9FFFF SVP board II (fourth) Main card 7
FA0000 - FA7FFF SVP board II (fifth) FFDE60 - FFDE7F Not-use area
FA8000 - FAFFFF Timing board FFDE80 - FFDEBF Main card 13
FB0000 - FCFFFF CRP board II FFDEC0 - FFDEDF Main board IIB
FD0000 - FEFFFF Not used area FFDEE0 - FFDEEF ECP card 2 (first)
FF0000 - FF7FFF System I/O area FFDEF0 - FFDEFF ECP card 2 (second)
FF8000 - FFCFFF Not-used area FFDF00 - FFDFBF Main board IIB
FFD000 - FFDFFF Local I/O area FFDFCO - FFDFEF Main board IIB, bubble card
FFE000 - FFFFF Not-used area FFDFF0 - FFDFFF Main board, bubble card, main card 6, BE
board
Address Board and card
FF7E30 - FF7E3F EC BOARD ( E3 ) or EC CARD
FF0000 - FF003F CRT board (for 300 panel for OH) FF7E40 - FF7E7F HC BOARD (MOP unit)
FF0040 - FF6FFF Not-used area FF7E80- FF7EBF DATA BOARD (RS-232C 1ch.)
FF7000 - FF77FF ECBUS board FF7EC0 - FF7EDF DATA BOARD (RS-232C 2ch.)
FF7800 - FF78FF RS board (sixth) FF7EE0 - FF7EFF DATA BOARD or FDC BOARD
FF7900 - FF79FF RS BOARD (fifth) FF7F00 - FF7F1F DATA BOARD (printer: centronics)
FF7A00 - FF7AFF RS BOARD (fourth) FF7F20 - FF7F3F Graphic board IG or graphic board
FF7B00 - FF7BFF RS BOARD (third) FF7F40 - FF7F5F HDC board
FF7C00 - FF7CFF RS BOARD (second) FF7F60 - FF7F7F OSP500 CRP board
FF7D00 - FF7DFF RS BOARD (first) FF7F80 - FF7F9F Not-used area
FF7E00 - FF7E0C EC BOARD ( E0 ) FF7FA0 - FF7FBF Not-used area
FF7E10 - FF7E1F EC BOARD ( E1 ) or EC Card FF7FC0 - FF7FDF (for DNC)
FF7E20 - FF7E2F EC BOARD ( E2 ) or EC Card FF7FE0 - FF7FFF OSP5 (remote display unit)
* 1 Addresses of main
cards are those when they
are mounted on ECP
board II.
*2 Addresses of IJP cards
and ECP cards are those
when they are mounted
on main board II.
*3 Two digits from the
left are ignored. Six digits
from the right are
effective.
FFDE20 - FFDE5F
