Okuma OSP 5000 - Functions Available When the MDI Mode Key Is Pressed; Functions Available When the MANUAL Mode Key Is Pressed

4-14
Okuma America Corporation
Machining CenterMachining Center
Machining CenterMachining Center
Machining Center
Rev. 8-21-01
MDI
The following shows the functions available when the MDI mode key is pressed. All the functions
are the same as in AUTO except for the DATA INPUT (F1) function.
MANUAL
The following shows the functions available when the MANUAL mode key is pressed. All the
functions are the same as in DATA INPUT except F1 is blank.
DATA
INPUT
ACTUAL
POSIT
PART
PROGRAM
BLOCK
DATA
SEARCH ATC/APC CHECK
DATA EXTEND
F1 F2 F3 F4 F5 F6 F7 F8
Press this key
and then
enter desired
codes to
perform MDI
functions
Used to
display
coordinates
of the actual
position of
the axes in
relation to the
zero offset
Used to
display a
part
program
Used to
display the
data in one
BLOCK
DATA
Used to
search for
particular
Check
Data
screen
Used to
display the
status of
the ATC
or APC
Used to
display
I/O signals
and
various
other data
Used to
access
other
menus
ACTUAL
POSIT
PART
PROGRAM
BLOCK
DATA
SEARCH ATC/APC CHECK
DATA EXTEND
F1 F2 F3 F4 F5 F6 F7 F8
Used to
display
coordinates
of the actual
position of
the axes in
relation to the
zero offset
Used to
display a
part
program
Used to
display the
data in one
BLOCK
DATA
Used to
search for
particular
Check
Data
screen
Used to
display the
status of
the ATC
or APC
Used to
display
I/O signals
and
various
other data
Used to
access
other
menus
TOOL
SET
PART
PROGRAM
BLOCK
DATA
SEARCH ATC/APC CHECK
DATA EXTEND
F1 F2 F3 F4 F5 F6 F7 F8
