Access Address (MB II, MB II A)
Address Board and Card Address Board and Card *1
000000 - 07FFFF Main board II F00000 - F1FFFF ECP board II and Card 1-II (volatile RAM)
080000 - 0FFFFF Main card 1-II or 5-II F20000 - F77FFF Not-used area
100000 - 1FFFFF Main card 5-II F78000 - F7BFFF ECP board II and card 1-II (non-volatile RAM)
200000 - AFFFFF Use-inhibited area F7C000 - F7CFFF Main card 2 (panel 1F)
B00000 -B00007 Main board II F7D000 - F7DE3F Not-used area
B00008 - B03FFF Main board II F7DE40 - F7DE5F ECP card 4-II
B04000 - B07FFF Not-used area F7DE60 - F7DEF7 ECP card 3 (PG, EC I/O)
B08000 - BFFFFF User inhibited area F7DE80 - F7DEBF Main card 3 (RS232C)
C00000 - E77FFF Not-used area F7DECO - F7DEDF Main card 3 (puncher, centronics)
E78000 - E7FFFF OSP5 CRP board (RX-CRP board) F7DEE0 - F7DEFF ECP card 2 (EC I/O)
E80000 - EFFFFF ECP board II (second) F7DF00 - F7DF3F Not-used area
F00000 - F7FFFF ECP board II (first) or IJP board F7DF40 - F7DF5F ECP card 4-II
F80000 - F87FFF SVP board II (first) F7DF60 - F7DF9F Not-used area
F88000 - F8FFFF SVP board II (second) F7DFA0 - F7DFBF Main card 2-II of main card 2, 4
F90000 - F97FFF SVP board II (third) F7DFCO - F7DFFF Not-used area
F98000 - F9FFFF SVP board II (fourth) F7E000 - F7FCFF Use-inhibited area
FA0000 - FA7FFF SVP board II (fifth) F7FD00 - F7FFFF ECP board II(D/A, R1C, encoder, ECBUS)
FA8000 - FAFFFF Timing board
FB0000 - FCFFFF CRP board II Address Board and Card *2
FD0000 - FEFFFF Not-used area FFD000 - FFD05F IJP card 3 (AD)
FF0000 - FF7FFF System I/O area FFD060 - FFDO7F IJP card 5 (DA, PHP, FEED-P)
FF8000 - FFBFFF AXIS board FFD080 - FFD09F IJP card 6 (differential transformer)
FFC000 - FFCFFF Operation panel for OSP5000M-G FFD0A0 - FFDCFF Not-used area
FFD000 - FFDFFF Local I/O area FFDD00 - FFDE1F Main board II (DMA)
FFE000 - FFFFFF Not-used area FFDE20 - FFDE5F Main card (RS-422)
FFDE60 -FFDE7F Main board 2-II (general purpose switch)
FFDE80 - FFDEBF Main board 3 (RS232C)
FFDEC0 - FFDEDF Main board 3 (FACIT punch)
FFDEE0 - FFDEFF ECP card 2
FFDF00 - FFDE1F Main board II
FFDF20 - FFDF5F (Main board)
FFDF60 - FFDF9F Main board II (RTC, PTM,DIA)
FFDFA0 - FFDFBF Main card 2-II (PTR) or (Main card 2,4)
FFDFCO - FFDFCF Main board II (bubble card (first))
FFDFD0 - FFDFDF Main board II (bubble card (common))
FFDFEO - FFDFEF Main board II (bubble card (second))
FFDFF0 - FFDFFF Main board II, Main card 6, BE board (bubble
card)
Address Board and Card FF7E30 - FF7E3F EC BOARD (fourth) or EC CARD
FF0000 - FF003F CRT board (for 300 panel for OH) FF7E40 - FF7E7F HC BOARD (MOP unit)
FF0040 - FF6FFF Not-used area FF7E80- FF7EBF DATA BOARD (RS-232C 1ch.)
FF7000 - FF77FF ECBUS board FF7EC0 - FF7EDF DATA BOARD (RS-232C 2ch.)
FF7800 - FF78FF RS board (sixth) FF7EE0 - FF7EFF DATA BOARD or FDC BOARD
FF7900 - FF79FF RS BOARD (fifth) FF7F00 - FF7F1F DATA BOARD (printer: centronics)
FF7A00 - FF7AFF RS BOARD (fourth) FF7F20 - FF7F3F Graphic board IG or graphic board
FF7B00 - FF7BFF RS BOARD (third) FF7F40 - FF7F5F HDC board
FF7C00 - FF7CFF RS BOARD (second) FF7F60 - FF7F7F OSP500 CRP board
FF7D00 - FF7DFF RS BOARD (first) FF7F80 - FF7F9F Not-used area
FF7E00 - FF7E0C EC BOARD (first) FF7FA0 - FF7FBF Not-used area
FF7E10 - FF7E1F EC BOARD (second) or EC Card FF7FC0 - FF7FDF (for DNC)
FF7E20 - FF7E2F EC BOARD (third) or EC Card FF7FE0 - FF7FFF OSP5 (remote display unit)
*
1 Addresses of main cards
are those when they are
mounted on ECP board II.
*2 Addresses of IJP cards
and ECP cards are those
when they are mounted on
main board II.
*3 Two digits from the left
are ignored. Six digits from
the right are effective.
