INPUT OUTPUT VERIFY
D-PIP
QUIT
F1 F2 F3 F4 F5 F6 F7 F8
Inputs
A.TOP file
from
peripheral
device
Outputs
A.TOP file
to
peripheral
device
Compares
data sent
to or from
peripheral
with data
in memory
Used to
terminate
data
transfer
procedure
ZERO SET
SET ADD CAL
BACK
UP
F1 F2 F3 F4 F5 F6 F7 F8
Used to set
new data
Used to
add to
currently
stored data
Calculates
data from
the actual
position
(RAPA)
Used to immediately back
up data. On newer OSP
5020 (1994 and newer)
